E-SMG Serie Single Cylinder Cone Crusher

E-SMG Serie Single Cylinder Cone Crusher is widely applied to metallurgy, construction, hydropower, transport, chemical and building material industries and suitable for crushing variety of hard and above middle-hard ores and rocks.
E-SMG Serie Single Cylinder Cone Crusher
Call on us: +86-21-5820 5268Email: sanme@sanmecrusher.com

E-SMG Serie Single Cylinder Cone crusher is advanced technology of cone crusher in the world, not only provides the features of high reliability, but also with the features of high crushing efficiency, low operation cost, good shape of the end products.

Feature and Advantage:

1.Optimized cavity, higher capacity,better quality
E-SMG series hydraulic cone crusher is designed for optional variety of cavities. By selecting suitable cavities and eccentricity, it ensures the producing demand of customer in maximum and realizes high capacity.

2.Resistant wear part consumption and low operation cost
The discharging open can be adjusted timely and conveniently with hydraulic adjusting design, which realizes full load operation, lowers wear parts consumption and reduces operating cost.

3.Easy cavities exchange
Due to the same body structure, we can get different crushing cavity by changing liner plate to fulfill the various processing for coarse and fine crushing.

4.Advanced hydraulic technology offers easy operation and maintenance
Due to adopting advanced hydraulic technology, overload protection can effectively be realized, which simplify the structure of crusher and reduces its weight. All maintenance and inspection can be fulfilled on the top of crusher, which ensures easy maintenance.

5.Large feeding opening design
Large feeding opening design is adopted by S type E-SMG series cone crusher to provide good combination with primary jaw crusher, which greatly improves the crushing capacity. While processing gravels, it can replace jaw crusher and be used as primary crusher.

Working principle:

The crushing structure of E-SMG series single-cylinder hydraulic cone crusher makes the crusher adjustment conveniently, and can adjust the discharge opening freely and simply. The intelligenceauto- control system can keep the crusher at the best work situation, and realizes automatic compensation function between the plate of inner and outer awls.We can set and adjust the discharge opening exactly through the operation panel, also can fulfill the wearing capacity of wear part by several buttons on the control panel. Meanwhile, by adopting the single-cylinder structure, the whole crusher body is compact and greatly reduces the channel for oiling and adjustment structure outside.

Technical Data of E-SMG Series Secondary Cone Crushers

Model Power (Kw) Cavity Max Feeding Size (mm) CSS(mm) CapaCity(t/h)
22 25 29 32 35 38 41 44 48 51 54 60 64 70 80 90
E-SMG100S 90 EC 240 85-120 100-145 105-155 110-165 120-145 130-
C 200 80-115 85-125 90-115 100-120
E-SMG200S 160 EC 360 150 155-245 160-260 165-270 175-280 176-290 190-305 200-280 210-250 226
C 300 160-195 170-280 180-290 190-300 200-315 210-330 216-305 235
M 235 135-210 140-225 145-235 155-245 160-260 170-270 176-245 190
E-SMG300S 220 EC 450 265-316 280-430 292-450 300-470 325-497 335-445 345-408
C 400 290 300-460 312-480 325-505 340-450 360-420 370
M 300 250-390 260-410 280-425 290-445 300-405 315-375 330
E-SMG500S 315 EC 560 330-382 345-515 356-590 375-625 390-645 405-670 433-716 450-745 475-790 520-750
C 500 350-465 360-600 375-625 395-660 410-685 425-705 455-756 475-710 504-590
E-SMG700S 500-560 EC 560 820- 1100 860-1175 930-1300 980-1380 1050-1500 1100-1560 1150-1620
C 500 850- 1200 890-1260 975-1375 1020-1450 1100-1580 1150-1580 1200-1700

Model Power (Kw) Cavity Max Feeding Size (mm) CSS(mm) CapaCity(t/h)
6 8 10 13 16 19 22 25 32 38 44 51 57 64 70
E-SMG100 90 EC 150 48-86 52-90 58-100 60-105 65-110 75- 130
C 90 42-55 45-90 50-95 52-102 55-110 60-120 70-
M 50 36-45 37-75 40-80 45-75 48-60
F 38 28-50 30-55 32-58 35-50
E-SMG200 132-160 EC 185 68- 108 75-150 80-160 85-170 90-180 105-210 115-210
C 145 65- 130 70-142 75-150 80-160 85-175 95- 195 108-150
M 90 65-85 70- 130 75-142 80-150 86-160 90-155 102-
F 50 48-80 50-85 52-90 60-95 63-105 68-105 72-95 75
E-SMG300 220 EC 215 112-200 120-275 130-295 140-315 160-358 175-395 190-385
C 175 110-218 115-290 125-312 130-330 150-380 165-335 180-230
M 110 115-185 125-278 135-300 145-320 150-340 175-280 195-
F 70 90-135 95-176 100-190 110-205 120-220 125-235 135-250 155-210
E-SMG-500 315 EC 275 190-335 200-435 215-465 245-550 270-605 295-660 328-510
C 215 170-190 180-365 195-480 210-510 235-580 260-645 285-512 317-355
MC 175 160-250 170-425 185-455 195-485 225-550 250-500 275-365
M 135 190-295 210-440 225-470 240-500 270-502 300-405
F 85 185-305 210-328 225-350 240-375 255-400 290-400
E-SMG700 500-560 ECX 350 450-805 515-920 570-1015 625-1115 688-1220 740-1320 800- 1430 865-1260
EC 300 475-850 540-960 600-1070 658-1170 725-1290 780-1390 840- 1510 900-1330
C 240 430-635 460-890 525- 1020 580-1125 635-1230 700-1350 750-1460 820- 1460 875-1285
MC 195 380-440 405-720 430-837 490-950 544-1055 590-1155 657-1270 708-1370 769- 1370 821-1205
M 155 400-560 425-785 455-835 520-950 573-1050 628-1150 692-1270 740-1370 810- 1250 865-1095
F 90 360-395 385-655 415-705 440-750 470-800 535-910 590-855 650-720
E-SMG800 710 EC 370 560- 1275 610-1410 680-1545 740-1700 790-1835 850- 1990 910-2100
C 330 570- 1350 620-1480 690-1615 760-1780 810-1920 870- 2050 930-2020
MC 260 520-1170 600- 1340 645-1485 720-1620 780-1785 835-1930 900-1910 950-1650
M 195 500-910 540-1050 630-1190 670-1325 730-1450 790-1590 850-1700 930-1710
F 120 400-670 500-832 530-880 570-940 660-1060 690-1150 750-1010
E-SMG900 710 EFC 100 210-425 228-660 245-715 260-760 275-810 315-925 350-990 380-895
EF 85 200-585 215-630 225-670 245-720 260-770 300-870 330-970 360-1060
EFF 75 190-560 210-605 225-650 240-695 250-740 290-845 320-890

Fine crusher cavity type: EC=Extra Coarse, C=Coarse, MC=Medium Coarse, M=Medium, F=Fine

The crusher capacities listed are based on instantaneous sampling of medium hardness material. The above data are for reference only, please contact our engineers for equipment selection of specific projects.

Note: The table of production capacity can be used as reference for the initial selection of E-SMG series cone crushers. The data in the table applies to the production capacity of materials with a bulk density of 1.6t/m³, feeding materials smaller than the discharging particle size have been screening out, and under the open circuit operation conditions. Crusher as an important part of the production circuit, its performance depends partly on the correct selection and operation of feeders, belts, vibrating screens, support structures, motors, transmission devices and bins.
